Hollyland Pyro 5 - 4K Wireless Transceiver Monitor 5.5" 1500nits brightness
Features
- Monitor Wireless Video up to 1312' Away
- 5.5" Touchscreen 1920 x 1080 Display
- Transmitter & Receiver Mode Switching
- Transmit/Receive 4K30 SDI/HDMI Video
- One Transmitter Can Send to 4 Receivers
- High 1500 cd/m² Brightness
- Auto Frequency Hopping, 2.4/5 GHz Bands
- RTMP Streaming, USB/SD Card Import/Save
- Built-In L-Series Battery Plate
Hollyland PYRO 5 4K – Product Overview
Transmit, receive, and monitor high-quality wireless video with the versatile Hollyland Pyro 5 4K Wireless Transceiver Monitor. Building on the original Pyro 5, this upgraded model now supports end-to-end 4K30 transmission and adds integrated camera control functionality. It retains the bright 5.5" touchscreen, L-series battery compatibility, up to 1312 ft transmission range, SD card recording, HDMI/SDI connectivity, RTMP streaming, and more.
Auto Dual-Band Hopping & Smart Channel Selection
Equipped with Auto Dual-Band Hopping (ADH) and Auto Frequency Hopping (AFH) across both 2.4 GHz and 5 GHz bands, the Pyro 5 4K automatically selects the optimal frequency for stable and interference-free transmission. These technologies help mitigate signal congestion, interference, and transmission inefficiencies. High-gain omnidirectional antennas further enhance signal stability in all directions. For manual control, Smart Channel Selection allows users to scan and switch channels using visual signal indicators.
Flexible Transmission Modes: Direct & Broadcast
Fully compatible with the Pyro ecosystem, the Pyro 5 4K supports flexible wireless workflows:
- Direct Mode: Connect one transmitter to up to two receivers and two mobile devices at distances up to 1312 ft (line-of-sight).
- Broadcast Mode: Expand transmission to up to four receivers with stable signals up to 656 ft.
Bright 5.5" Touchscreen Display
The integrated 5.5-inch monitor delivers 1500 cd/m² brightness, ensuring clear visibility in both bright outdoor and low-light environments. Adjustable brightness settings allow for optimal viewing under any condition.
Integrated Camera Control
Control key camera parameters directly from the touchscreen, including ISO, aperture, shutter speed, white balance, and focus mode. Tap-to-focus functionality is also supported. Compatible with select Sony cameras via an optional control cable.
Versatile Input & Output Options
The Pyro 5 4K can operate as either a transmitter or receiver:
- Transmitter Mode: 1 × HDMI input, 1 × SDI input, 1 × HDMI loop output
- Receiver Mode: 1 × HDMI output
Quick Multicam Switching
Group multiple Pyro devices for seamless multicam workflows. Instantly switch monitoring between two cameras using customizable shortcut buttons, improving efficiency on set.
Lock Pairing for Stable Connections
In multi-system environments, Lock Pairing ensures each receiver remains linked to its designated transmitter, preventing signal crossover or interference.
Extended Range & Low Latency
With dual-band 2.4/5 GHz transmission, the Pyro 5 4K delivers stable video up to 1312 ft with minimal latency:
- Smooth Mode: ~60 ms latency with adaptive bitrate for longer distances
- HD Mode: Up to 12 Mb/s bitrate with ~75 ms latency for optimized image quality
Built-in RTMP Streaming
Stream directly to platforms such as Zoom, YouTube Live, Twitch, and TikTok Live via RTMP, making it ideal for live production and content creation workflows.
SD Card Recording & Workflow Integration
An integrated SD card slot supports MP4 recording (up to 40 minutes per session). Users can:
- Apply custom LUTs during export
- Organize files efficiently for post-production
- Import external data and overlay screenshots for scene matching and continuity
Efficient Proxy Recording
Record proxy files directly to SD while monitoring in real time. Files are automatically organized and include timecode for seamless syncing with camera footage, enabling faster editing workflows.
Advanced Image Tools
Custom shortcut buttons provide quick access to essential monitoring tools, including:
- Waveform
- Focus assist
- Touch-to-focus
- Recording controls
- Additional image analysis features
These tools enhance on-set precision and streamline monitoring operations.
Specs
Key Specs
| Display Size |
5.5" / 14.0 cm |
| Native Resolution |
1920 x 1080 |
| Touchscreen |
Yes |
| HDR Support |
No |
| Media/Memory Card Slot |
Single Slot: SD (Unspecified Type) [Record/LUT/Firmware] |
| Wireless |
2.4 GHz Radio/RF / 5.8 GHz Radio/RF |
| Video Format |
HDMI |
| Battery |
1x L-Series Mount on Fixed Plate |
Display
| Panel Type |
LCD |
| Display Size |
5.5" / 14.0 cm |
| Native Resolution |
1920 x 1080 |
| Aspect Ratio |
16:9 |
| Touchscreen |
Yes |
| Maximum Brightness |
1500 nits / cd/m2 |
| Contrast Ratio |
1000:1 |
| HDR Support |
No |
| Color Gamut |
100% Rec. 709 |
| LUT Support |
Yes |
| Image Controls |
Anamorphic De-Squeeze, False Color, Focus Assist, Histogram, Vectorscope, Waveform, Zebra |
Inputs/Outputs
| Antenna I/O |
2x RP-SMA |
| Video I/O |
1x HDMI 1.4b Input |
| Embedded Audio |
HDMI: 8-Channel |
| Audio I/O |
1x 1/8" / 3.5 mm Headphone Output |
| Built-In Speaker |
No |
| Power I/O |
1x Barrel (18 VDC) Input |
| Other I/O |
1x USB-C 2.0 |
| Media/Memory Card Slot |
Single Slot: SD (Unspecified Type) [Record/LUT/Firmware] |
Wireless
| Wireless |
2.4 GHz Radio/RF / 5.8 GHz Radio/RF |
| Wireless Range |
1312.3' / 400 m (Line-of-Sight) |
| Channel Bandwidth |
40 MHz and 20 MHz |
| Frequency Range |
5.15 to 5.25 GHz |
| Latency |
60 ms |
| RF Power |
< 23 dBm |
| RF Sensitivity |
-85 dBm |
| Wi-Fi |
No |
| Bluetooth |
No |
| Mobile App Compatible |
Yes: Android & iOS |
Format Support
| Video Format |
HDMI |
| Video Signal Conversion |
No |
| Audio Format |
2-Channel |
Power
| Input Power |
10 to 18 VDC |
| Battery |
1x L-Series Mount on Fixed Plate |
| Power Consumption |
16 W |
Mounting
| Tripod/Accessory Mounting |
1/4"-20 Female |
What's in the box:
1 x Hollyland Pyro 5 4K Wireless Transceiver Monitor
2 x Short Antenna
1 x 1/4"-20 Screw to Cold Shoe Mount Adaptor
1 x USB-C to USB-C Cable
1 x USB-C OTG Adapter
1 x Tempered Glass Screen Protector
(HL-Pyro5-4K)
| SKU | HL-Pyro5-4K |
| Barcode # | 6976068119906 |
| Brand | Hollyland |
| Artist / Author | Hollyland Pyro 5 - 4K Wireless Transceiver Monitor 5.5" 1500nits brightness |
| Shipping Weight | 1.0000kg |
| Shipping Width | 0.230m |
| Shipping Height | 0.110m |
| Shipping Length | 0.160m |
| Shipping Cubic | 0.004048000m3 |
