Blackmagic Design Streaming Encoder HD
Items Included
- Blackmagic Design Streaming Encoder HD
- Welcome Wallet with QR Code for Software Download
- Limited 3-Year Manufacturer Warranty
Key Features
- H.264 & H.265 Streaming to SRT or RTMP
- 12G-SDI Input & Loop Output
- 1080p Streaming up to 60 fps
- Ethernet 10/100/1000BASE-T Support
- SDI & HDMI Monitor Outputs
- Integrated 2.2" LCD Screen
- USB-C for Phone Tethering & Webcam Out
- Tethers to 4G & 5G Phones for Streaming
- Front Panel Buttons & Spin Knob
- 100-240 VAC & 12 VDC Power Inputs
The encoder is equipped with 12G-SDI connectivity, supporting input resolutions up to UHD 4K60 via an SDI input and 3G-SDI via an SDI loop output. The unit also features SDI and HDMI monitor outputs. Video, audio, status, and menu settings may be monitored via the integrated 2.2" LCD screen. There is also an option to connect the device as a webcam to a computer via its rear-panel USB-C port. The front panel features six buttons and a spin knob for tactile control, and the unit may be powered via its rear 100-240 VAC and 12 VDC 4-pin XLR ports.
Blackmagic Design Streaming Encoder HD Specs
Key Specs
| IP Video |
H.264/H.265: |
| Video I/O |
1x BNC (12G-SDI / 3G-SDI / 6G-SDI / HD-SDI) Input |
| Embedded Audio |
SDI Input: 16-Channel |
| Power Consumption |
(25 W) |
| Display |
LCD |
IP Encoding/Decoding
| IP Video |
H.264/H.265: |
| Transport Protocols |
RTMP, SRT |
| Compatible Services |
Facebook Live, Twitch, YouTube Live |
Wireless
| Wireless |
No |
| Wi-Fi |
No |
| Bluetooth |
No |
| Cellular Support |
5G NR / 4G LTE via Unspecified SIM Type |
Interfaces
| Video I/O |
1x BNC (12G-SDI / 3G-SDI / 6G-SDI / HD-SDI) Input |
| Other I/O |
1x RJ45 Fast Ethernet Input/Output |
| Embedded Audio |
SDI Input: 16-Channel |
Power
| Power I/O |
1x IEC C14 Input |
| Power Consumption |
(25 W) |
General
| Operating Conditions |
32 to 104°F / 0 to 40°C at 0 to 90% Humidity |
| Storage Conditions |
-4 to 113°F / -20 to 45°C at 0 to 90% Humidity |
| Display |
LCD |
| Rackmount Size |
1 U |
| Dimensions |
6.9 x 5.5 x 1.75" / 17.5 x 14 x 4.45 cm |
| Weight |
1.66 lb / 753 g |
(BDLKWEBCSEDHD)
| SKU | BDLKWEBCSEDHD |
| Barcode # | 9338716010039 |
| Brand | Blackmagic Design |
| Shipping Weight | 3.0000kg |
| Shipping Width | 0.450m |
| Shipping Height | 0.550m |
| Shipping Length | 0.150m |
