Hollyland Syscom Transimitter for 421S

$2,385.00
Only 1 Left!





Pick-up from the store - $0.00
Please wait for our phone call to confirm pick up details. Pick up address: Shop 2, 8-10 The Ave, Hurstville, NSW 2220.

Features:

  • 1800ft Transmission Range
  • The Lowest Achievable Latency without Interference is under 0.1s
  • 5.1-5.9 GHz Band Width, Supports Frequency Configuration for Different Territories
  • Supports 4 SDI Input and HDMI Input, 4SDI Output and HDMI Output
  • 4 Transmitters Use the Same Wireless Channel with Strong Anti-Interference Ability
  • Supports TALLY and RS485/RS422 Control
  • Transmitter Supports 7-36V DC Wide Voltage Input
  • Receiver Supports 18-36V DC Wide Voltage Input
  • Stable & Reliable Industrial Metal Case
  • With RJ45 Interface, Supports Network Pass Through between Transmitter and Receiver, and Achieves RTSP Pull and Push Streaming

Interface

  • SDI Input (BNC Female)
  • HDMI Input (Type A Female)
  • 3.5mm TALLY Output
  • Antenna Interface*4 (RP-SMA Male)
  • DC Power Input
  • USB Type-C
  • LAN
  • RS485/RS422

Input/Output Video Format

  • HDMI: 480p60Hz, 576p50Hz, 720p50/60Hz, 1080p24/25/30/50/60Hz
  • SDI: 720p50/60Hz, 1080i50/60Hz, 1080p24/25/30/50/60Hz


Bandwidth:

  •  40MHz

Lowest Transmission Latency:

  • <0.1s

Receiver Sensitivity:

  • -90dBm

Transmission Power:

  • Max 22dBm

Frequency:

  • 5.1~5.9HGz

Power:

  • 7~36V DC

Power Consumption:

  • <12W

Weight:

  • 431.5g (without antenna)

Dimensions:

  • 3.46 x 1.18 x 5.66" (without antenna)



(HL-SYSCOM421STX)

SKU HL-SYSCOM421STX
Barcode # 6970758743822
Brand Hollyland
Shipping Weight 1.0000kg
Shipping Width 0.230m
Shipping Height 0.110m
Shipping Length 0.160m
Shipping Cubic 0.004048000m3
